Dealer Phone: Body Size: 00-14 Fret
510 SYCAMORE STREET, NAZARETH, PENNSYLVANIA 18064 USA, 800-633-2060800-633-2060 FAX: 484-291-6639
– CUSTOM ORDER INVOICE –
Dealer No: 888888-0 Instrument: CUSTOM with CASE Case,CstmShop,5-Ply,HS,00-14F,Silver
Dealer Name: Custom Edition Quantity: 3
Delivery After Receipt Of Order AND Deposit:
SPECIAL INSTRUCTION: Hide Glue Bridge, Neck, Braces, Top & Back to Body
LABEL: none
CONSTRUCTION: Standard; Mahogany Blocks/Dovetail Neck Joint
BODY SIZE: 00-14 Fret
TOP: SINKER MAHOGANY
TOP GRADE: N/A
TOP BRACES: Adirondack/Scalloped 1/4”/Golden Era
PATTERN: 00-14 Fret 12A
TOP BINDING: Faux Tortoise – Brown
TOP INLAY: .070” B/W/B/W/B Boltaron
TOP PEARL: None
ADDITIONAL TOP INLAY: None
ROSETTE: Old Style 18
PEARL INLAY: None
ADDITIONAL ROS. INLAY: None
PICKGUARD: Delmar, Faux Tortoise 3071,Self-Ad, Pattern 13B (Old Style 0018)
PEARL INLAY: None
BACK: Sinker Mahogany
BACK PANELS: 2 Pc.
PURFLING: Style 18
CENTER STRIP/LOC. STAMP: Sitka Spruce Standard(CF Martin & Co Nazareth PA Made in USA Btwn 1st/2nd Brace)
CAUTION STAMP: None
BACK BINDING: Faux Tortoise – Brown
BACK INLAY: None
BACK PEARL: None
ADDITIONAL BACK INLAY: None
SIDES: Sinker Mahogany
SIDE INLAY: None
SIDE PEARL: None
ADDITIONAL SIDE INLAY: None
ENDPIECE: Delmar Tortoise Brown 3071
ENDPIECE INLAY: None
ENDPIECE PEARL: None
ADDITIONAL EP INLAY: None
BLOCK: Solid Genuine Mahogany
TAG/PLATE: None
REAR: 000 Sinker Mahogany
FRONT: 00/000-14 Fret Sinker Mahogany
Line 1: C. F. Martin Logo
Line 2: Custom Shop Logo
Line 3: Serial #
Line 4:
Line 5:
NECK: Sinker Mahogany 12/4
NECK SHAPE: Mod V
HEADSTOCK: Solid/6 String No Diamond/Square Taper
BACK/HEAD STAMP: None
TRUSS ROD: 2-Way Adjustable 356mm
HEELCAP: Black Ebony
NUT: Bone
ON ANGLE/FLAT: Flat
HEADPLATE: Madagascar Rosewood
HEADPLATE DECAL: Golden Era
HEADPLATE BIND: None
HEADPLATE INLAY: None
HEADPLATE PEARL: None
ADDITIONAL HP INLAY: None
TUNING MACHINES: Waverly (#4067-G) Gold w/Black Ebony Knobs (Drill 11/32
FINGERBOARD: Black Ebony
RADIUS: 16”
SCALE LENGTH: 24.840” (24.9”)
WIDTH AT NUT: 1 3/4”
WIDTH AT 12 FRET: 2 1/4”
FRET WIRE: G300
FRETS CLEAR: 14
TOTAL FRETS: 20
FINGERBOARD BIND: None
FINGERBOARD INLAY: None
PEARL INLAY: Old Style 18 (Abalone)
ADDITIONAL FB INLAY: None
SIDE DOTS: White Boltaron
SIDE DOT POSITION: One at 3rd, 5th, 7th, 9th, Two at 12th, One at 15th & 17th Frets
FINISH TYPE: Gloss/Satin Neck
FINISH BODY: Non-Catalyzed Gloss/ Authentic Stain/ Dark Filler
FINISH TOP: Non-Catalyzed Gloss/ Authentic Stain/ Dark Filler
FINISH NECK: Non-Catalyzed Satin/ Authentic Stain/ Dark Filler/Polished Headplat
BRIDGE: Black Ebony
STYLE: Vintage Belly- Drop In Long Saddle
PEARL INLAY: None
ADDITIONAL BR INLAY: None
STRING SPACING: 2 1/4”
SADDLE: 16” Radius/Bone- Drop In Long Saddle
ELECTRONICS: None
STRAP BUTTON: None
STRINGS: LifeSPan MSP 7100 Light Strings
BRIDGE PINS: Ebony
END PIN: Ebony
